禾伸堂建立in-house功能陶瓷材料实验室，拥有自制陶瓷材料配方技术，生产一系列积层陶瓷电容，其中包括标准品和客制品，以满足市场多变需求。透过先进的工厂利用最新设备与科技，满足多变的客制化商品需求。
禾伸堂工厂通过ISO 9001及14001认证，车用电容产品取得严格的IATF 16949认证，安规电容亦拥有许多国际安规认证。
为提供完整服务，在陶瓷电容领域我们也特别加强应用性之特定产品与技术如下：
1. 高压低电容量产品线：HVC-X7R, NP0 (100V至10000V)
2. 中压高电容量产品线：HVC-X7R, X7S, X6S, X6R (50V至100V, up to 1uF)
3. 低温飘系数，low bias材料：X7P
4. SMD型UL60950/X2与Y2/X1安规认证电容
5. 软端子技术积层陶瓷电容 (SuperTerm)
6. 高效能稳定供电High CV Class 1 (NP0/CoG)陶瓷电容
7. 堆栈式之积层陶瓷电容
MVC
Medium voltage for commercial and industrial applications, NP0 and X7R available with rated voltage from 100V to 630V, in size from 0603 to 2225.
HVC
High voltage for commercial and industrial applications, NP0 and X7R available with rated voltage from 1KV to 8KV, in size from 0603 to 2225.
NCC
General use, for decoupling circuits. NP0, X7R, X5R available with rated voltage ranging from 6.3V to 50V, in size 0201 to 1206 with capacitance from 0.5pF to 820nF.
HCC
High capacitance for smooth (DC to DC) and decoupling circuits. Available in X7R, X7S, X6S, X5R at 4.0V to 50V, in size from 0201 to 2220 with capacitance from 1uF to 220uF.
HCN
High capacitance for ADSL/xDSL application (replacement for film capacitor). NP0 available with rated voltage from 16V to 50V, in size from 0603 to 2225 with capacitance from 1nF to 120nF.
SCC
Safety capacitor for isolation and protection circuits (UL, EN class X1/Y2, and X2). Available in NP0 and X7R at AC 250V to AC 305V, in size 1808 to 2825 with capacitance from 2.0pF to 56nF.
Automotive Grade Capacitors
Suitable for harsh automotive environment with no additional qualification testing. AEC-Q200 certified, available in NP0 and X7R, at 16V to 1KV, in size 0805 to 2220 with capacitance ranging from 10pF to 10uF.
HCP
Competitive price compared to X7T dielectric, made to meet general requirement. X7P is available, rated voltage from 250V to 630V, in size from 1206 to 2220 with capacitance from 10nF to 680nF.
HCT
Made to meet general requirement. X7T is available, rated voltage from 250V to 630V, in size from 1206 to 1812 with capacitance from 10nF to 470nF.
